P464 Two Speed,Steel Hydraulic Hand Pump, Double-Acting Cylinders
-
Model:P464
Pump Type:Double Speed
Used with Cylinder:Double-Acting Cylinders
Usable Oil Capacity: 7423cm³
Max.Operating Pressure: 700 bar
Pressure Rating 1st Stage: 25bar/348.1 psi
Pressure Rating 2nd Stage:700bar/10000 psi
Oil Displacement Per Stroke 1st Stage (cm³)126.2
Oil Displacement Per Stroke 2nd Stage (cm³)4.75
Weight:27.7 kg
Minimum Order:1Piece
Manufacturer:SAIVS
Country of Origin:China
Brand Name:Replacement Enerpac's P464
Description
Model:P464
Product Line: Industrial Tools
Customizable with special requirement
Two-speed operation,can reduce the intensity of the operator.
P-84 and P-464 are equipped with 4-way valve,they can be used to operate the
double action cylinders.
Other models are equipped with external unloading valve,they can be
used to operate the single action cylinders.
The inemal safety valve is equipped to protect the pump while overloading.
The capacity of oil tank is big enough to match a wide range of cylinders and tools.
Two-speed is to be used in the situation of hydraulic pommel should reach the
heavy object quickly or need a great quantity fuel.For example,driving two or more
Hydraulic Cylinders is recommended to use it.
With a choice of oil capacities up to 453 in3 (7423 cm3), you will find Steel Hand Pumps that can handle multiple cylinder hook-ups,
including models to suit either Single-Acting and Double-Acting cylinders.
Durable Stainless Steel structure.
Two-speed operation, build-in automatic pressure valve to provide greater flow at low pressure, saving operation time and increasing the work efficiency.
Build-in safety valve provides dual-protection of safety.
Pressure regulating valve can readjust working pressure.
The unique press rod mechanism for easy operating.
Integral three-position four-way valve on P464 for double-acting Hydraulic Cylinders
SAIVS's hydraulic hand pump is designed for portability, durability and easy-of-use.
A large selection of hydraulic hand pumps makes it easy to find the most effective compact high pressure pump.
The manual hand is also equipped with numerous Safety Features to provide dependable performance, while maintaining worker safety.
Dimensions
| Model Number | A | B | C | D | E | F | H | J | L | M | N | P | Q | R | S | T |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| P392 | 393 | 520 | 35 | 38 | 32 | - | 464 | 30 | 119 | 65 | 133 | - | - | - | - | - |
| P80 | 425 | 539 | 25 | 44 | 54 | - | 527 | 29 | 174 | 19 | 146 | 121 | - | 21 | 8 | 67 |
| P84 | 425 | 510 | 25 | 44 | - | 64 | 527 | 29 | 174 | 19 | 146 | 121 | 38 | 43 | 8 | 67 |
| P462 | 210 | 308 | 163 | 320 | 195 | - | 671 | 25 | 270 | 175 | 650 | 92 | - | - | - | - |
| P464 | 210 | 308 | 163 | 320 | 195 | - | 671 | 25 | 270 | 175 | 650 | 92 | 89 | 68 | 80 | - |
| Model Number | Pump Type | Usable Oil Capacity (cm3) | Pressure Rating (bar) | Oil Displacement per Stroke (cm3) | Max. Handle Effort (kg) | Piston Stroke (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| P392 | Double speed | 655 | 1st stage: 25 2nd stage: 700 | 1st stage: 15 2nd stage: 2.62 | 50 | 20.6 | 5.9 |
| P80 | 2200 | 1st stage: 25 2nd stage: 700 | 1st stage: 16.22 2nd stage: 2.46 | 47 | 25.4 | 10.9 | |
| P84 | 2200 | 1st stage: 25 2nd stage: 700 | 1st stage: 16.22 2nd stage: 2.46 | 49 | 25.4 | 13.2 | |
| P462 | 7423 | 1st stage: 14 2nd stage: 700 | 1st stage: 26.20 2nd stage: 4.75 | 49 | 38.1 | 27 | |
| P464 | 7423 | 1st stage: 14 2nd stage: 700 | 1st stage: 26.20 2nd stage: 4.75 | 49 | 38.1 | 27.7 |
