P392 Two Speed,Single-acting Hydraulic Steel Hand Pump
-
Model:P392
Pump Type:Double Speed
Used with Cylinder:Single-Acting
Usable Oil Capacity: 655 cm³
Max.Operating Pressure: 700 bar
Pressure Rating 1st Stage: 25bar/348.1 psi
Pressure Rating 2nd Stage:700bar/10000 psi
Oil Displacement Per Stroke 1st Stage: 15cm³
Oil Displacement Per Stroke 2nd Stage: 2.62cm³
Weight:5.9 kg
Minimum Order:1Piece
Manufacturer:SAIVS
Country of Origin:China
Description
With a choice of oil capacities up to Reservoir Capacity:655-7423cm
Flow at Rated Pressure: 2.46-4.75cm'/stroke
Maximum Operating Pressure:700 bar / 10000 Psi
you will find Steel Hand Pumps that can handle multiple cylinder hook-ups,
including models to suit either Single-Acting and Double-Acting Cylinders.
1. Durable Stainless Steel structure..
2. Two-speed operation, build-in automatic pressure valve to provide greater flow at low pressure,
saving operation time and increasing the work efficiency.
3. Build-in safety valve provides dual-protection of safety.
4. Pressure regulating valve can readjust working pressure.
5. The unique press rod mechanism for easy operating.
SAIVS's hydraulic hand pump is designed for portability, durability and easy-of-use.
A large selection of hydraulic hand pumps makes it easy to find the most effective compact high pressure pump.
The manual hand is also equipped with numerous Safety Features to provide dependable Performance, while maintaining worker safety.
Dimensions
P392 Two Speed,Single-acting Hydraulic Steel Hand Pump
| Model Number | A | B | C | D | E | F | H | J | L | M | N | P | Q | R | S | T |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| P392 | 393 | 520 | 35 | 38 | 32 | - | 464 | 30 | 119 | 65 | 133 | - | - | - | - | - |
| Model Number | Pump Type | Usable Oil Capacity (cm3) | Pressure Rating (bar) | Oil Displacement per Stroke (cm3) | Max. Handle Effort (kg) | Piston Stroke (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| P392 | Double speed | 655 | 1st stage: 25 2nd stage: 700 | 1st stage: 15 2nd stage: 2.62 | 50 | 20.6 | 5.9 |
| P80 | 2200 | 1st stage: 25 2nd stage: 700 | 1st stage: 16.22 2nd stage: 2.46 | 47 | 25.4 | 10.9 | |
| P84 | 2200 | 1st stage: 25 2nd stage: 700 | 1st stage: 16.22 2nd stage: 2.46 | 49 | 25.4 | 13.2 | |
| P462 | 7423 | 1st stage: 14 2nd stage: 700 | 1st stage: 26.20 2nd stage: 4.75 | 49 | 38.1 | 27 | |
| P464 | 7423 | 1st stage: 14 2nd stage: 700 | 1st stage: 26.20 2nd stage: 4.75 | 49 | 38.1 | 27.7 |
